BEQ-5 | Bass EQ Pedal


Dial it up. Dial it in. Let us begin.

It seems like regular EQ pedals are really easy to come by, but that's not always the case for Bass EQ's. Guitars and Basses generally sound at different frequencies, so it's important that you have the right EQ for each. The BEQ-5 from CNZ focuses on a primary series of bass frequencies with 5-band adjustments set from 62.5Hz to 4 kHz. This gives you adjustable parameters for your deep bass tones, while still being able to adjust for articulation beyond 1kHz. This is a cost-effective and simple way to add more versatility to your favorite bass rig.


  • 5 Band Equalizer
  • Metalic Silver with Dotted Graphics
  • Five Thin Slider Controls
  • Green LED Clear Volume Knob Adjusts Level
  • 62.5Hz, 125Hz, 500Hz, 1kHz & 4kHz Settings
  • Sliders Adjust from 0 to +18 dB and – 18 dB
  • True Bypass Provides Transparent Tone in Off Mode
  • Solid Aluminum Housing with Firm Foot Switch


  • Dimensions: 3.75 L x 1.77 W x 1.9H Inches
  • 9VDC Input (- center, + outside), 8 mA
  • 470K Ohms Input Impedance
  • 1K Ohms Output Impedance
  • .54 lbs (including box)
  • Solid Aluminum Housing on All Sides
  • 1/4 Inch Input and Output Mono Connectors
